INNOSILICON™ introduces its LPDDR6/5X PHY and Controller IP, purpose-built for the AI era’s high-performance chip design needs. This solution is fully compliant with JEDEC LPDDR6/5X standards, delivering ultra-high speed with exceptional power efficiency.
The LPDDR6/5X IP integrates high-performance DDR-specific I/Os, a dedicated Timing Synchronization Module (TSM), and a programmable low-power, low-jitter DLL. With fine-grained control and robust adaptability, it ensures reliable memory interactions and optimized energy efficiency across diverse LPDDR6/5X applications—including varying loads, temperatures, and voltage fluctuations—meeting the rigorous demands of long-term chip operation.
In LPDDR6 mode, the dual-protocol compatible LPDDR6/5X Combo PHY enables peak data rates of up to 14.4Gbps per channel. This makes it an ideal memory interface solution for applications requiring both extreme bandwidth and low power consumption, such as AI training and inference accelerators, advanced autonomous driving domain controllers, high-end consumer electronics, and performance-driven storage systems.
Leveraging the synergy of “core IP + complete solution”, INNOSILICON™ LPDDR6/5X one-stop IP solution supports leading process nodes, helping customers mitigate the technical risks of developing LPDDR6/5X IP. It shortens integration cycles for LPDDR interfaces in the high-performance chips and empowers customers to gain a competitive edge in next-generation high-speed memory solutions.
